Excellent stepless adjusting mechanism allows a micro adjustment of the meter.
High accuracy and repeatablility over the widest range of flow, superior accuracy at constant flow.
Low maintenace, no metal-to-metal contact in measuring chamber, long life service.
Accuracy regardless of pressure fluctuations, temperature variation, viscosity.
Choice of aluminum, cast iron and stainless steel materials of construction.
Technical Parameter |
Size | 50mm/2" |
Flow rate | 38-380L/min | 55-550L/min |
Volume Per Revolution | 0.681L |
Max.pressure | 20Bar |
Accuracy | ±0.2% |
Repeatability | ≤0.05% |
Standard measurement | Liter/US Gallon/IMP Gallon |
Package | 1pc/wooden case |
N.W. | 44kgs |
G.W. | 47kgs |
Meas. | 69x59x57cm |
